Technical Parameters
Sample type
Whole blood, serum, plasma, throat swab, puncture fluid, etc.
Nucleic acid extraction method
Automated magnetic bead method
Wide processing volume range
Can extract samples with a volume of 20 – 1000 μl
High magnetic bead recovery rate
Magnetic bead recovery rate is above 98%
High heating temperature accuracy
Two independent heating modules, customize the lysis temperature according to needs
Multi-speed oscillation mixing
Multiple speeds are adjustable, and the oscillation amplitude can be adjusted according to the reagent volume
Complete internal program
Built-in 12 sets of mode programs, you can add or import parameters independently
Unique safety door design
Automatically pause the program after the safety door is opened, and continue to run the program after the safety door is closed to avoid cross infection
Built-in air duct design
Unique built-in air duct design can avoid cross infection
Power failure safety protection
Support power failure protection function, continue to run after power is restored
Well plate type
96-well plate, can be adapted to a single six-tube reagent kit
Number of magnetic rods:
96
Purification sensitivity:
10IU/ML sample positive detection rate>95%
Lysis temperature:
25℃-90℃
Sample throughput
96 sample channels
Extraction time
15-60 minutes/round (determined by the reagents used)
Extraction well difference
CV ≦3%
Screen operation
7-inch high-resolution color touch screen
Instrument expansion interface:
Standard RS232 interface
Disinfection method:
Built-in UV lamp disinfection
Exhaust method:
Fan
Ambient temperature:
10℃–40℃
Relative humidity
80%
Power supply:
AC110-220V, 50/60HZ
